Rexroth管式過濾器，力士樂過濾器濾芯，Rexroth力士樂管式過濾器憑借以下特點脫穎而出：高效的特殊過濾器介質； 可在較大壓差范圍內吸附非常細小的顆粒；過濾面積大，納污能力強；過濾器濾芯耐腐蝕性良好；過濾器濾芯的抗壓強度高（如冷啟動時）；過濾器精度等級為3μm至 100 μm ；默認配備具記憶功能的目視維護指示器；借助計算機 3D 技術輔助設計的流動優化設計

力士樂管式過濾器的公稱壓力250bar[3628psi]，最大接口尺寸G1 1/2；SAE1 1/2；SAE24，工作溫度為–10°C至100℃[14°F至212°F]

Rexroth帶旁通的管式過濾器，過濾精度等級為 3 μm

245LEN0040-H3XLA00-V5，0-M-R2 R928030024   245LEN0040-H3XLA00-V5，0-M-U3 R928030216 濾芯：R928006645
245LEN0063-H3XLA00-V5，0-M-R4 R928030025   245LEN0063-H3XLA00-V5，0-M-U4 R928030217 濾芯R928006699
245LEN0100-H3XLA00-V5，0-M-R4 R928030026   245LEN0100-H3XLA00-V5，0-M-U4 R928030218  濾芯R928006753
245LE0130-H3XLA00-V5，0-M-R5 R928030027    245LE0130-H3XLA00-V5，0-M-U5 R928030219  濾芯R928022274
245LE0150-H3XLA00-V5，0-M-R5 R928030028    245LE0150-H3XLA00-V5，0-M-U5 R928030220  濾芯R928022283
245LEN0160-H3XLA00-V5，0-M-R6 R928030029   245LEN0160-H3XLA00-V5，0-M-U6 R928030221 濾芯R928006807
245LEN0250-H3XLA00-V5，0-M-R6 R928030030   245LEN0250-H3XLA00-V5，0-M-U6 R928030222  濾芯R928006861
245LEN0400-H3XLA00-V5，0-M-R6 R928030031   245LEN0400-H3XLA00-V5，0-M-U6 R928030223 濾芯R928006915

Rexroth帶旁通的管式過濾器，過濾精度等級為 6 μm

245LEN0040-H6XLA00-V5，0-M-R2 R928030280  245LEN0040-H6XLA00-V5，0-M-U3 R928030472 濾芯：R928006646
245LEN0063-H6XLA00-V5，0-M-R4 R928030281   245LEN0063-H6XLA00-V5，0-M-U4 R928030473 濾芯R928006700
245LEN0100-H6XLA00-V5，0-M-R4 R928030282   245LEN0100-H6XLA00-V5，0-M-U4 R928030474  濾芯R928006754
245LE0130-H6XLA00-V5，0-M-R5 R928030283    245LE0130-H6XLA00-V5，0-M-U5 R928030475 濾芯R928022275
245LE0150-H6XLA00-V5，0-M-R5 R928030284    245LE0150-H6XLA00-V5，0-M-U5 R928030476  濾芯R928022284
245LEN0160-H6XLA00-V5，0-M-R6 R928030285   245LEN0160-H6XLA00-V5，0-M-U6 R928030477 濾芯R928006808
245LEN0250-H6XLA00-V5，0-M-R6 R928030286   245LEN0250-H6XLA00-V5，0-M-U6 R928030478  濾芯R928006862
245LEN0400-H6XLA00-V5，0-M-R6 R928030287   245LEN0400-H6XLA00-V5，0-M-U6 R928030479 濾芯R928006916

力士樂Rexroth帶旁通的管式過濾器，過濾精度等級為 10 μm

245LEN0040-H10XLA00-V5，0-M-R2 R928030536 245LEN0040-H10XLA00-V5，0-M-U3 R928030728 濾芯：R928006647
245LEN0063-H10XLA00-V5，0-M-R4 R928030537   245LEN0063-H10XLA00-V5，0-M-U4 R928030729 濾芯R928006701
245LEN0100-H10XLA00-V5，0-M-R4 R928030538  245LEN0100-H10XLA00-V5，0-M-U4 R928030730  濾芯R928006755
245LE0130-H10XLA00-V5，0-M-R5 R928030539    245LE0130-H10XLA00-V5，0-M-U5 R928030731 濾芯R928022276
245LE0150-H10XLA00-V5，0-M-R5 R928030540    245LE0150-H10XLA00-V5，0-M-U5 R928030732  濾芯R928022285
245LEN0160-H10XLA00-V5，0-M-R6 R928030541   245LEN0160-H10XLA00-V5，0-M-U6 R928030733 濾芯R928006809
245LEN0250-H10XLA00-V5，0-M-R6 R928030542  245LEN0250-H10XLA00-V5，0-M-U6 R928030734  濾芯R928006863
245LEN0400-H10XLA00-V5，0-M-R6 R928030543   245LEN0400-H10XLA00-V5，0-M-U6 R928030735 濾芯R928006917
